ROHM Launches SiC Inverter Reference Designs to 300kW

ROHM just released three handy reference designs for three-phase inverter circuits “REF68005“, “REF68006“, and “REF68004” now live on their website. These pair perfectly with their EcoSiC™ SiC molded modules in “HSDIP20“, “DOT-247“, and “TRCDRIVE pack™ packages, giving designers ready-to-use drive circuit board data.

Pair them with ROHM’s SiC modules, and you can slash evaluation time while tackling high-power setups up to 300kW class for automotive and industrial gear. SiC brings efficiency and reliability, but thermal and peripheral design can be a grind these refs make it way easier.

The matching SiC modules are already available online via DigiKey and Farnell. Want the actual boards or eval kits, hit up a sales rep or ROHM’s contact page (quantities limited).

Quick note on online sales: Check the full lineup in ROHM’s recent announcement: New SiC Molded Modules Now Available!

Simulation & Design Support

ROHM’s got your back with full resources for fast eval and rollout:

• HSDIP20: Ref Design| ROHM Simulator | LTspice Model
• DOT-247: Ref Design| ROHM Simulator | LTspice Model
• TRCDRIVE pack™: Ref Design

Plus, dive into ROHM’s full reference designs hub for even more time-savers. Perfect for streamlining your SiC inverter projects!

About Reference Designs

These reference designs are intended for users to utilize the publicly released design data. If you would like to obtain a reference design board or evaluation kit, please contact a sales representative or visit the contact page on ROHM’s website. (Quantities are limited.)
