Latching power relay models have been added to Same Sky’s Relays Group’s lineup of power relays. The latching power relays in the PRL series come in single coil and double coil varieties, with maximum switching currents ranging from 10 to 20 A.
These latching power relays, which include silver alloy contact material and SPST (1 Form A), SPDT (1 Form C), and DPST (2 Form A) contact forms, can handle coil voltages ranging from 3 to 24 Vdc, maximum switching voltages of 277 Vac, and coil power ratings of 200 to 1200 mW. Additionally, all models have Class B coil insulation, flux sealing, and operating temperature ranges of -40 to 85°C.
The PRL family of latching power relays features single coil and double coil types with max switching currents from 10 to 20 A.
Key Features:
- Single coil or double coil latching,
- Max switching currents from 10 to 20 A
Offering SPST (1 Form A), SPDT (1 Form C), and DPST (2 Form A) contact forms with silver alloy contact material, these latching power relays carry coil voltages from 3 to 24 Vdc, max switching voltages of 277 Vac, and coil power ratings from 200 to 1200 mW.
All models further offer flux sealing, Class B coil insulation, and operating temperature ranges from -40 to 85°C.
Applications
Industrial automation, building automation, telecom, and more
Availability
Stock to 8 weeks
Cost: $1.64 per unit at 100 pieces through distribution
