Upgradeability has become crucial for extending device lifecycles, reducing redesigns, and enabling unique features when connection standards and market demands change. To overcome this challenge, Microchip Technology has introduced the highly integrated PIC32-BZ6 MCU that serves as a common, single-chip platform to decrease development cost, complexity and time-to-market for multi-protocol solutions offering advanced connectivity and scalability.
Key Features Include:
- High memory and scalable package choices to support demanding applications and OTA updates: The high-performance MCU includes 2 MB Flash memory and 512 KB RAM and is available in 132-pin ICs and modules with additional pin and package variants planned.
- Multi-protocol wireless networking: Qualified against Bluetooth Core Specification 6.0, the device also supports 802.15.4-based protocols such as Thread and Matter plus proprietary smart-home mesh networking protocols.
- Design flexibility that extends product options and scaling opportunities: Versatile and comprehensive selection of on-chip peripherals goes beyond wireless connectivity and OTA updates to support:
- Wired connectivity: Multiple interfaces include two CAN-FD ports for automotive and industrial communication, a 10/100 Mbps Ethernet MAC for high-speed wired connectivity and a USB 2.0 full-speed transceiver for seamless data transfer and PC integration.
- Touch and graphics: Incorporates peripherals that enable advanced user interfaces including Capacitive Voltage Divider (CVD)-based touch capabilities with up to 18 channels.
- Motor control: Simplifies system development through advanced analog peripherals such as 12-bit ADCs, 7-bit DAC, analog comparators, PWMs and QEI for precise motor position and speed control.
- Security by design to protect applications and IP: Includes immutable secure boot in ROM and an advanced on-board hardware-based security engine supporting AES, SHA, ECC and TRNG encryption.
- Reliability in harsh environments: The device is qualified to AEC-Q100 Grade 1 (125 °C) specifications for automotive and industrial environments.
Wireless solutions usually need multiple chips to add new capabilities or regular redesigns to match changing industry standards, and RF design for smart devices has grown more complex.
With a single, highly integrated chip that eliminates the complexity of multi-protocol wired and wireless communication, the PIC32-BZ6 MCU takes the place of these multi-chip solutions and lessens the redesign burden.
Along with touch and graphical capabilities for sophisticated user interfaces, expanded memory to enable complex programs, heavy workloads, and Over the Air (OTA) firmware updates, the MCU also has analog peripherals to make motor control development easier.
Product development for smart home, automotive connectivity, industrial automation, and wireless motor control use cases is streamlined by the PIC32-BZ6 MCU platform.
Leadership Comments
“The PIC32-BZ6 MCU stands out for its powerful blend of connectivity, integration and flexibility in a single-chip solution,” said Rishi Vasuki, vice president of Microchip’s wireless solutions business unit. “Few devices bring together this breadth of features in a single chip, and we’re already seeing strong tremendous early adopter activity. Customers are leveraging its multi-protocol wireless capabilities, advanced analog features and high I/O to develop smarter, more connected products with greater efficiency.”
Development Tools
Microchip simplifies development and product certification for the PIC32-BZ6 MCU by offering proven chip-down reference designs and wireless design check services, helping to minimize design risk. To further ease regulatory compliance, pre-certified modules are available in multiple regions worldwide.
The PIC32-BZ6 MCU family is supported by the PIC32-BZ6 Curiosity Board that enables testing of all MCU I/Os, connectivity and peripheral features.
Developers also benefit from a comprehensive development environment through Microchip’s MPLAB® Integrated Development Environment (IDE) and the Zephyr® Real Time Operating System (RTOS).
Pricing and Availability
The PIC32-BZ6 MCU platform currently includes the PIC32CX2051BZ62132 System on Chip (SoC), ideal for multi-protocol wireless applications requiring advanced connectivity and extensive I/O, and the PIC32WM-BZ6204UE RF-certified module, designed for rapid integration into wireless products with streamlined certification and reduced time-to-market.
The SoC and the module are available for $3.73 and $5.84 each, respectively, in 10,000-unit quantities. Additional package and module options are planned to further expand design flexibility and address a broader range of application needs.
